Product Introduction
VXB-15 Series Indoor High-Voltage AC Generator Circuit Breaker
Product Overview:
The VXB-15 series indoor high-voltage AC generator circuit breaker is designed for generator control and protection. It simplifies plant power switching procedures, facilitates unit commissioning and maintenance, enhances equipment protection capabilities, and improves system stability. Installing dedicated generator circuit breakers represents the most effective and economical measure for protecting generators and transformers. Suitable for new power plants (thermal, hydroelectric, nuclear, pumped storage) and retrofits of existing plants, they also serve as control and protection switches for large substations and high-load industrial/mining enterprises. Complies with GB/T14824, GB/T1984, and other relevant standards.
Product Features:
▲The product boasts compact dimensions, high insulation strength, pollution-free operation, and no explosion hazard.
▲High mechanical and electrical service life.
▲Utilizes domestically produced high-quality arc extinguishing chambers for excellent cost-effectiveness.
▲Integrated design of mechanism and circuit breaker employs a dedicated spring-operated mechanism, ensuring rational design and high reliability.
▲This circuit breaker offers high breaking capacity and stable performance.
▲The circuit breaker can be conveniently installed in draw-out switchgear such as KYN28.
▲The product meets environmental protection requirements throughout its design, manufacturing, and service life.
Key Technical Specifications:
|
NO. |
Parameter Name |
Unit |
Numerical value |
||||
|
1 |
Rated Voltage |
kV |
15 |
||||
|
2 |
Rated Current |
A |
4000 |
5000 |
6300 |
||
|
3 |
Rated Frequency |
Hz |
50 |
||||
|
4 |
Rated Short-Circuit Breaking Current |
kA |
50 |
80 |
|||
|
5 |
Rated Short-Circuit Making Current |
kA |
137 |
220 |
|||
|
6 |
Rated Peak Withstand Current |
kA |
137 |
220 |
|||
|
7 |
Rated Short-Time Withstand Current |
kA |
50 |
80 |
|||
|
8 |
Rated Short-Circuit Duration |
s |
4 |
||||
|
9 |
Rated Operating Sequence |
|
CO-30min-CO |
||||
|
10 |
Outgoing Terminal Short-Circuit Barrier Test |
|
75% |
||||
|
11 |
Rated Insulation Level |
1-Minute Power Frequency Withstand Voltage |
To Ground and Between Poles |
kV |
54 |
||
|
Between Breaks |
59 |
||||||
|
12 |
Lightning Impulse Withstand Voltage |
To Ground and Between Poles |
kV |
100 |
|||
|
Between Breaks |
102 |
||||||
|
13 |
Breaking Time |
ms |
≤80 |
||||
|
14 |
Mechanical Life |
time |
10000 |
||||
|
15 |
Number of Breaks at Rated Short-Circuit Current |
time |
8 |
||||
|
16 |
Number of Operations at Rated Load Current |
time |
50 |
||||
|
17 |
Arc Duration |
ms |
≤15 |
||||
|
18 |
OP1 |
kA |
40(DC component＜20%) |
||||
|
19 |
OP2 |
kA |
40(DC component75%) |
||||
