VXB-40.5(P) Series Indoor AC High-Voltage Vacuum Circuit Breaker
- Free Samples
- Quality Assurance
- 24/7 Customer Service
Product Introduction
VXB-40.5(P) Series Indoor AC High-Voltage Vacuum Circuit Breaker
Product Overview：
The VXB-40.5(P) Series Indoor AC High-Voltage Vacuum Circuit Breaker is a new generation of draw-out vacuum circuit breakers developed by our company to meet the demands of the domestic power market. It is suitable for indoor high-voltage distribution equipment with three-phase AC 50Hz and a rated voltage of 40.5kV. It can be used for receiving, controlling, distributing, and protecting electrical energy in industrial and mining enterprises, power plants, and substations.
The product complies with relevant national standards such as GB and DL, as well as international standards like IEC, achieving performance levels equivalent to M2-E2-C2.
Product Features：
▲Complies with GB/T1984-2014 and DL/T403-2017 standards.
▲The circuit breaker features a rational, aesthetically pleasing, and streamlined overall layout.
Primary conductive circuits can utilize solid-sealed busbars or standard insulating tubes to accommodate diverse customer requirements.
▲Features a modular spring mechanism with superior performance and enhanced mechanical stability, suitable for high-frequency operation. Meets M2-class requirements with a mechanical life of up to 20,000 operations.
▲Rated current up to 4000A, rated short-circuit breaking capacity up to 40kA.
▲Flexible cabinet configuration options include circuit breakers with pole spacings of 300mm/440mm, compatible with 1400mm/1680mm wide KYN61 switchgear. Custom non-standard products can also be manufactured according to user requirements.
Key Technical Specifications：
|
NO. |
Project |
Unit |
Parameters |
|
1 |
Rated voltage |
kv |
40.5 |
|
2 |
Rated frequency |
Hz |
50 |
|
3 |
Rated current |
A |
1250,1600,2000,2500,3150,4000 |
|
4 |
Rated Short-Circuit Breaking Current |
kA |
20,25,31.5,40 |
|
5 |
Rated Short-Circuit Closing Current |
kA |
50,63,80,100 |
|
6 |
Rated Short-Circuit Withstand Current |
kA |
20,25,31.5,40 |
|
7 |
Rated Peak Withstand Current |
kA |
50,63,80,100 |
|
8 |
1-minute power frequency withstand voltage (RMS) |
kV |
95 (Phase-to-phase, phase-to-ground/break) |
|
9 |
Lightning impulse withstand voltage |
kV |
185 (Phase-to-phase, phase-to-ground/break) |
|
10 |
Rated Short-Circuit Duration |
s |
4 |
|
11 |
Rated Operating Sequence |
|
0-0.35-CO-1805-CO |
|
12 |
Rated Short-Circuit Breaking Cycles |
Time |
30 |
|
13 |
Mechanical life |
Time |
20000 |
|
14 |
Rated Operating Voltage |
V |
AC110/220,DC110/220 |
OEM/ODM Services:
At Shaanxi Yuguang Electric Co., Ltd., we understand the importance of customization. That's why we offer comprehensive OEM and ODM services to meet your specific requirements. Whether you need private labeling or custom product development, our experienced team is here to assist you every step of the way.
Certificates:
We take pride in our commitment to quality and safety. Our products are certified to meet the highest industry standards, including:
3C Certification
ISO 9001 Certification
21 Utility Model Patents and Design Patents
Why Choose Us:
State-of-the-art Manufacturing Equipment
Extensive Testing Facilities
Comprehensive Quality Assurance Processes
ISO 9001 Certified Quality Management System
One-year Warranty on All Products
Large Production Capacity
FAQ:
Q: What is the warranty period for your products? A: We offer a one-year warranty on all our products.
Q: Can you customize products according to our specifications? A: Yes, we provide OEM and ODM services to meet your specific requirements.
Q: Are your products compliant with international standards? A: Yes, our products meet all relevant international standards.
Q: What is the lead time for orders? A: The lead time depends on the quantity and customization requirements. Please contact us for more information.
Q: Do you provide technical support? A: Yes, we offer comprehensive technical support to our customers.
Packaging:
Wooden Box Packaging
Carton Packaging
Foam-filled Packaging
Waterproof and Moisture-proof Packaging
Customized Packaging
International Standard Packaging
Logistics:
Sea Freight
Air Freight
Land Transportation
Multimodal Transport
Express Delivery Services
Contact Us:
Ready to take your electrical projects to the next level? Contact us today at ygvcb@hotmail.com to discuss your requirements and explore partnership opportunities with Shaanxi Yuguang Electric Co., Ltd. Let's create a brighter future together.
