Lw3-12 Sulfur Hexafluoride Circuit Breaker

Ⅰ Product Overview:

Lw3-12 Sulfur Hexafluoride Circuit Breaker is a type of high-voltage electrical equipment suitable for power transmission and distribution systems. This product is widely used in various fields such as power plants, substations, industrial and mining enterprises, petrochemicals, metallurgy, and other urban power grid systems.

The switch structure is compact, the layout is reasonable, and all the tests meet the requirements of primary and secondary fusion of the State network; The unified parameter protection CT, zero sequence CT and zero sequence voltage sensor has the characteristics of wide measuring range, high measuring accuracy and high reliability, and complete analog quantity is convenient to accurately determine various line faults.

Ⅱ Structure:

Lw3-12 Sulfur Hexafluoride Circuit Breaker comprises several essential components, including an operating mechanism, interrupter unit, and control cabinet. The operating mechanism provides energy required for switching operation, and it can be manually or electrically operated.

The interrupter unit includes an SF6 arc-extinguishing chamber, contact system, and other auxiliary devices. The SF6 circuit breaker uses SF6 gas as an arc-extinguishing and insulating medium to achieve excellent breaking and short-circuit current interruption performance. The contact system is used to establish and break the circuit. The control cabinet comprises a control circuit, protection devices, and other auxiliary devices used to control and protect the circuit breaker.

Ⅲ Main Technical Parameters:

Ⅳ The main features:

1. The main box shell of the circuit breaker is made of 3mm stainless steel plate, which is a fully sealed structure, the protection grade is IP67, and the annual leakage rate of SF6 gas shall not be greater than 0.5%.

2. The shell is located on the ground easy to observe, obvious opening and closing position indicator, the indicator is reliably connected with the operating mechanism, indicating reliable action. The surface of the shell is raised, and it will not store water for a long time.

3. the diameter of 12mm anti-rust ground screw, ground point marked with grounding symbol.

4. The shell has a handling handle to avoid pulling out the line casing. The hoisting ring can keep the switchgear in suspension level, and there is no friction contact between the hoisting chain and any part, so as to avoid scratching the spray layer on the surface of the box during the hoisting process.

5. The circuit breaker is configured with three-phase current transformer, zero sequence current transformer and zero sequence voltage sensor. Current transformer ratio: phase current 600/1 (5); Zero sequence current 20/1; Accuracy level: The measurement accuracy level is 0.5, and the protection is 10P(5P10). Zero sequence current accuracy level 10P5; Zero sequence voltage accuracy class is 3P. Measurement and protection CT capacity: >1VA (600A/1A), >2.5VA (600A/5A) zero-sequence CT capacity: 20.5VA, to meet the supporting requirements (considering the cable length of 12 meters, cooperate with FTU and line loss module to meet the line loss measurement and fault determination requirements).

6. configuration and interface with a common box structure, spring mechanism. The circuit breaker has a set of built-in current transformer to provide 1a, Ib, Ic, I0 current signals. A zero sequence voltage sensor is built into the circuit breaker. Aviation socket, aviation plug and cable should be fully sealed waterproof structure.

Ⅴ Advantages:

Functional and safe performance are good.

Compact switch structure, reasonable layout,

All tests are in line with the requirements of primary and secondary fusion of the State grid;

It has the characteristics of wide measuring range, high measuring accuracy and high reliability, and complete analog quantity, which is convenient to accurately determine various faults of the line.
